特點:
采用全回轉式的大斧與大梭子,適合于粗線縫制,堅固,耐久的機構設計,適合于縫制大的物品和中厚的物料。車縫時送料精準,上下層之物料不會滑動,所以縫目美觀。大旋梭、上下送料,使縫制厚料更輕松。適用于集裝袋、帳篷、椅墊、拋光輪(布輪)、馬具、皇馬袋、汽車車篷、防水布、箱包類、牛仔等之縫制。
Characteristics:
Adopts full-rotating big axe and shuttle that is suitable for thick thread sewing.Adopt strong and durable mechanism design that is applicable for swing large objects and extra-thick materials.Accurate feeding during machine sewing;upper and lower materials will slide so seams and stitches are beautiful.Large rotating shuttle and upper and lower feeding make it easier to sew thick materials.suitable for shipping sack,tent,seat cushion,buff wheel(cottobvheel),horse gear,R-Madrid bag,vehicle hood,waterproof cloth,luggage and denim,etc.
主要技術參數Main Parameters:
型號 Model |
DS2570 |
用途 Application |
厚料 Heavy-Extra heay |
縫速高達 Max.Sewing speed |
1200s.p.m |
線跡長度 Stitch length |
0-12.7mm |
針桿行程 Needle bar stroke |
;50.8mm |
壓腳提升 Presser food lift
|
手提 By hand |
12.7mm |
膝控 By knee |
18mm |
機針 Needle size |
DD×1 27# |
旋梭 Rotating hook |
KRT132 |
操作空間 Opereting |
400mm×180mm |
電動機 Motor |
550mm |
